Substance Painter Asset Series

Each asset was produced to shipping standard first and turned into a chapter second. Every bake, generator and hand-painted mask in the course exists because it was needed here, not because it made a tidy lesson.

The brief was awkward on purpose. Six props had to escalate cleanly in difficulty — a steel pot you can texture in an afternoon through to a sniper rifle with wood, three metals and a scope — while each one stayed defensible as portfolio work on its own. An asset built only to demonstrate a feature looks like an asset built only to demonstrate a feature, and a student can tell.

The constraint that shaped everything was that the whole set had to survive being looked at closely, in Marmoset and in engine, at whatever resolution the viewer chose. That ruled out the usual shortcut of hiding a weak bake under a heavy grunge layer. So the series is bake-first: real chamfers on every visible edge of the high-poly, a cage generous enough that nothing clips and tight enough that nothing skews, baking by mesh name so a bolt never projects onto the plate behind it, and every mesh map inspected on its own before a single layer went down. Curvature and thickness carry most of the wear on all six; where a generator could not reach — the vent slats and the grille recesses on the air conditioner — the mask was built by hand in Photoshop and brought back in.

Budgets were held to game rather than to render. The props sit between roughly 8k and 40k triangles, the rifle highest because a scope and a bipod are geometry no normal map recovers. Texel density is held at 10.24 pixels per centimetre across the set, which is what keeps a 4K set on the rifle looking like the same world as a 2K set on the pot. Every asset ships one 4K texture set unless a second material was genuinely needed, and the sci-fi blade is the one that takes two, because a painted-steel base and a layered emissive blade do not share a roughness range.

The look-development pass is Marmoset for all six, with the lighting rig kept identical between them so the set reads as one body of work rather than six lucky renders. Two — the Nordic axe and the sniper rifle — carry on into Unreal Engine, transferred onto a lower-poly mesh and re-authored where the engine's shading disagreed with the offline render, which is the part of the pipeline most tutorials leave out and most studios ask about.

What shipped: six textured assets with high-poly source, low-poly meshes, UV layouts and full texture sets; the Marmoset scene files; the Unreal setup for two of them; and, downstream, twenty-three hours of video across the six projects that more than 1,500 students have worked through.

Project gallery
